about hydraulic pipe bending machine
Home » HOT » Hydraulic Pipe Bending Machine
What Information You Can Know About Hydraulic Pipe Bending Machine Here?
Which Hydraulic Pipe Bending Machine Is Perfect For You?
Pick Your Hydraulic Pipe Bending Machine
hydraulic tube bending machine including electric hydraulic pipe bending machine, cnc hydraulic pipe bending machine, hydraulic hand operated pipe bending machine from the combination with our technology and advanced Italian technology, This series adopt VDU hand operated touch screen operating panel, which can input, store, and display various bending data and order,Y, B, C three coordinates of motions under precision control by industrial computer can realize full-auto mandrel on or mandrel off rapid bending, CNC machine also with advanced functions, such as components bending spring back compensation, errors self diagnose alarm, memory store after power off, automatic lubrication and safety protection.
Hydraulic Tube Bender Sample Model Display

Hydraulic pipe benders are mainly used for pipe installation and repair in factories, warehouses, wharfs, buildings, railways, automobiles, etc. In addition to the pipe bending function, it can also remove the pipe bending part (cylinder) and use it as a separate hydraulic jacking machine.



These are the samples bent on our electric hydraulic pipe bending machine, CNC hydraulic pipe bending machine, hydraulic square pipe bending machine, hydraulic hand operated pipe bending machine you can show me your product photo, we can recommend you the suitable machine.

hydraulic NC pipe bending machine sample model
semi auto hydraulic pipe bending machine sample madel
hydraulic cnc tube bending machine sample model
semi auto hydraulic pipe bender sample model
hydraulic big tube bender sample model
Hydraulic Pipe Bending Have Different Advantages, Come And Match！

Hydraulic pipe bender is a new type of pipe bending tool with pipe bending function and lifting function. We provide including Hydraulic Motorized Pipe Bending Machine, hydraulic hand pipe bending machine, all has many advantages such as reasonable structure, safe use, convenient operation, reasonable hydraulic pipe bending machine price, fast loading and unloading, easy to carry, one machine with multiple functions.

Our professional experience and drawings plans for Electric, Electronic, Hydraulic and mechanical from known companies bring to the upgrading of the machines' systems to accurate and attractive performance.

  • Bender
    The pipe bender adopts touch screen and numerical control module, interactive operation, simple and easy program setting.
  • Bed Structure
    The bed structure is stable and not easy to deform.
  • Memory
    Each file can set 16 bending angles, and the memory can store 16 sets of files.
  • Slow Positioning
    With slow positioning function, the bending angle is stable, and the repeatability is up to ±0.1°.
  • Wrong Information
    The error message is displayed on the screen to help the operator eliminate it immediately.
  • Software
    Provide self-developed coordinate conversion elbow processing values, and the software can be installed on the desktop computer to edit and calculate.
  • Components
    The series was adapted in particular to professional world market requirements. All the parts, structures, and characters are similar to the standard of mechanical engineering from Europe.
Ask For A Hydraulic Pipe Bending Machine Quote

Fill out the form and you will be able to get the latest hydraulic pipe bending machine price and comprehensive project, write down your needs, we have the most professional to answer you。

GET TOUCH WITH US
Methods Of Hydraulic Tube Bender Use-The Ones You Want

How do you use a pipe bender safely?

There are four types of bends like hydraulic round pipe bending machine, hydraulic CNC pipe bending machine, hydraulic square pipe bending machine, Let us help you understand each process to help you find Safety Measures While Using Hydraulic Pipe Benders.

hydraulic tube bending machine

  • Seriously in operating the hydraulic tube bending machine

    A 1. The hydraulic system of the machine tool adopts YA-N32 ordinary hydraulic oil (the original brand No. 20), which is replaced once a year under normal circumstances, and the oil filter must be cleaned at the same time.
    2. The pressure of the hydraulic system cannot be greater than 14Mpa.
    3. When manually adjusting the speed of the side pushing cylinder, the rotating arm should be adjusted when it is rotated to ≥900. The adjustment speed is synchronized with the linear speed of the edge of the rotating elbow mold. It is forbidden to push the side pushing faster than the line of the edge of the rotating mold in the manual state. speed.
    4. In automatic operation in the core bending mode, before the bending arm returns, the operator must ensure that the core head is in the tube, or ensure that the mandrel is not blocked when the bending arm returns, otherwise, the core head or core rod may be Bend or break.

  • Do it carefully before operation the hydraulic pipe bender

    A 1. The machine tool must be well grounded, and the wire shall not be less than 4mm2 copper soft wire. It is not allowed to connect to a power supply voltage exceeding the specified range, plug-ins can not be plugged in and out of the plug when power is on, and the control circuit cannot be tested with a megohmmeter, otherwise the device may be damaged.
    2. When plugging and unplugging the connector, do not pull the wire or cable to prevent the welding from pulling off.
    3. Proximity switches, encoders, etc. cannot be hit by hard objects.
    4. Do not hit the display unit with sharp objects.
Hydraulic Tube Bender Videos
Hydraulic Pipe Bender Machine Maintenance Method
The Ones You Want Hydraulic Pipe Bending Machine Maintenance method，These methods are applicable to our hydraulic tube bender include hydraulic NC pipe bender, semi-auto hydraulic tube bending machine, hydraulic round tube bender, let's see it.
  • Hydraulic Pipe Bender
    The Hydraulic Pipe Bending Machine should be placed in a dry place indoors to avoid moisture so as to make the microelectronic equipment work effectively. Be sure to clean the machine between uses.
  • During Maintenance
    During Hydraulic Pipe Bending Machine maintenance, use the correct type of hydraulic oil to prevent internal components from sticking. Hydraulic oil should be replaced at least once a year. Do not use brake fluid, otherwise it may damage the machine.
  • High-pressure Hose
    If the high-pressure hose becomes dirty or contaminated, the hydraulic tube bender will not be able to work effectively. Make sure both ends are clean before use.
  • Install Control System
    Install a control system, such as Phenix More, to provide your maintenance manager with up-to-date, accurate information on the condition of the pipe bender so that problems can be detected and corrected early.
Your Most Concerned Hydraulic Pipe Bending Machine FAQ Is Here

  • Q Seriously in operating the hydraulic tube bending machine

    A
    1. The hydraulic system of the machine tool adopts YA-N32 ordinary hydraulic oil (the original brand No. 20), which is replaced once a year under normal circumstances, and the oil filter must be cleaned at the same time.
    2. The pressure of the hydraulic system cannot be greater than 14Mpa.
    3. When manually adjusting the speed of the side pushing cylinder, the rotating arm should be adjusted when it is rotated to ≥900. The adjustment speed is synchronized with the linear speed of the edge of the rotating elbow mold. It is forbidden to push the side pushing faster than the line of the edge of the rotating mold in the manual state. speed.
    4. In automatic operation in the core bending mode, before the bending arm returns, the operator must ensure that the core head is in the tube, or ensure that the mandrel is not blocked when the bending arm returns, otherwise, the core head or core rod may be Bend or break.

  • Q Before Sales Service:

    A
    1. We will help our customer confirm the right machine model according to the offered pipe information.
    2. Welcome to visit our factory to see our machine and our workshop before you place an order.

  • Q After Sales Service:

    A
    1. We provide a manual book, detailed machine installation, commissioning video to help you correctly operate the machine. If you need our engineer to go to your factory for machine installation, air tickets, food, hotel, local transportation should be at your
    account.
    2. If Any problems with the machine, our engineer will solve them for you through the computer first, most problems can be solved by changing parts, it can't, our engineer can go to your factory to solve them for you, we have experienced engineers especially for abroad market.
    For mechanical parts, which were made by ourselves, we have plenty in our stock, if you need, we can send to you by courier at once.
    For electronic parts, we all use famous brand, which you can buy it easily at your side.

  • Q which oil is used in hydraulic pipe bending machine?

    A
    For the JHPB-20 hydraulic bender it is usually recommended to use 820 ml of ISO VG 22 or ISO VG 32 hydraulic oil, for the JHPB-30 it is recommended to use 1700 ml. If necessary, lubricate lightly on all moving parts.
